XCZU15EG-2FFVC900I Overview
The XCZU15EG-2FFVC900I is a Zynq UltraScale+ MPSoC from the AMD Xilinx EG device family, combining a hardened multi-processor system with high-density 16 nm FinFET programmable logic on a single die. Supplied in the 900-ball FFVC900 package at -2 speed grade and industrial temperature rating, the XCZU15EG-2FFVC900I targets designs that need heterogeneous compute, deterministic real-time control and high-bandwidth serial I/O in one device.
Processing System (PS)
The EG suffix denotes the graphics-enabled variant. The XCZU15EG-2FFVC900I processing system integrates:
- Application Processing Unit — quad-core Arm Cortex-A53, 64-bit, with NEON and 1 MB shared L2 cache
- Real-Time Processing Unit — dual-core Arm Cortex-R5F with TCM, lock-step capable for functional-safety designs
- Graphics Processing Unit — Arm Mali-400 MP2 with 64 KB L2 cache
- Memory controller — multi-protocol 64-bit DDR4 / DDR3 / LPDDR4 / LPDDR3 with ECC
- Peripherals — USB 3.0, SATA 3.1, DisplayPort 1.2a, 4× Gigabit Ethernet, SD/eMMC, CAN, SPI, I²C, UART, GPIO
- PS-GTR — 4 transceiver lanes at up to 6 Gb/s serving PCIe Gen2, USB3, SATA, DisplayPort and SGMII
Programmable Logic (PL) Resources
| Resource | XCZU15EG |
|---|---|
| System logic cells | 747K |
| CLB LUTs | 341,280 |
| CLB flip-flops | 682,560 |
| Block RAM | 26.2 Mb (744 blocks) |
| UltraRAM | 31.5 Mb (112 blocks) |
| DSP slices (DSP48E2) | 3,528 |
| GTH transceivers | 16 @ 16.3 Gb/s |
| PCIe hard blocks | Gen3 x16 integrated block |
Package, Speed Grade and Temperature
| Attribute | Value |
|---|---|
| Manufacturer Part Number | XCZU15EG-2FFVC900I |
| Manufacturer | AMD (Xilinx) |
| Device | Zynq UltraScale+ MPSoC ZU15EG |
| Package | FFVC900, flip-chip BGA, 900 balls |
| Body size / pitch | 31 × 31 mm, 1.0 mm |
| Speed grade | -2 |
| Temperature grade | Industrial (I), -40 °C to +100 °C Tj |
| Process | 16 nm FinFET+ |
| Design tools | AMD Vivado Design Suite, Vitis Unified Software Platform |
Security and Configuration
The XCZU15EG-2FFVC900I includes a Configuration Security Unit supporting AES-GCM 256-bit decryption, RSA-4096 authentication, SHA-3/384 hashing and Arm TrustZone, alongside secure boot and tamper monitoring for defence, aerospace and infrastructure applications.
Typical Applications
- 5G and wireless remote radio units, massive MIMO beamforming
- Software-defined radio and RF signal processing
- Machine vision, medical imaging and industrial inspection
- Motor control, robotics and functional-safety industrial systems
- ADAS and automotive sensor fusion prototyping
- Test and measurement instrumentation
- Aerospace and defence embedded computing
Why Buy XCZU15EG-2FFVC900I from FPGA.io
FPGA.io supplies genuine AMD Xilinx programmable devices with full traceability. Every XCZU15EG-2FFVC900I is inspected and tested before shipment, backed by a warranty and supported by responsive technical and logistics teams. Contact FPGA.io for current XCZU15EG-2FFVC900I stock, pricing and lead time.
